Detail Skycom- Splicing Machine - T-207h ADVANCED

Applicable Fibers SM, MM, NZ-DS, EDF , Pigtail, Rubber-insulated wire Series Average Splice Loss 0.02dB( SM) , 0.01dB( MM) , 0.04dB( NZDS) , 0.04dB( EDF) Return Loss e60dB Tension Test 2.0N( 200gf) Standard Typical splicing/ heating time 10sec/ 30sec Splicing Program 50 groups Protection Sleeve Length 20mm, 40mm, 60mm Language English Operating condition -10+ 50

( operation temperature) , 0 95% RH( humidity) , 0 5000m( altitude) Power Supply AC100 240V input voltage, 50/ 60Hz; 12V, 5A output voltage( DC) / 12V voltage 8AH( inner Li-battery) Monitor 5 inches high Resolution colorful LCD display Fiber image magnification Simultaneous X and Y views with300 times magnification Storage of splice result 6, 000 groups of splice results. Optical Fiber Fixture 7 Fiber Fixtures & 4 Kinds of Fixtures Dimensions 130 W 135 D 130 H Weight 2.21kg( excluding battery) battery weight: 370g

Digital fiber optical fusion splicer SKYCOM T-207H Core alignment full featured auto splicing 3-IN-ONE fiber clamp high accuracy fiber splicing machine

Brand: SKYCOM

About this item

· Precise core alignment single fiber fusion splicer

· Typical 10s fast splicing; 30s fast heating

· 3-in-one universal fiber clamp (0.25mm,0.9mm & 3.0mm drop cable )

· Highly accurate, endurable and reliable

· Multipurpose 1+N fixture (SC/LC/FC connector)

Product description

Main features:

· 5 inches high resolution colorful LCD display, image can be turned according to position

· Average splice time: 10 seconds

· Average tube-heat time: 30 seconds

· Lithium battery: Rechargable and up to 200 times of continuous splice and heat

· X or Y axis Separately views with 360 times magnification, or Simultaneously 220 times

· Cutting-edge technology for image processing

· Splicing mode: Auto & Manual & Full-Auto

· Storing 6,000 groups of latest splice results

· New technology of fiber core alignment, enhanced accuracy

· New 3-in-1 cutting fixture for Drop cable, pigtail & bare fiber

· New Multipurpose 1+N fixture

Specifications:

1. Applicable Fibers SM, MM, NZ-DS, EDF, Pigtail, Cable (Drop cable),

2. SC/LC/FC connector (optional function)

3. Average Splice Loss 0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF)

4. Return Loss ≥60dB

5. Tension Test 2.0N(200gf)(Standard)

6. Typical splicing time 10 seconds

7. Typical heating time 30 seconds

8. Splicing Program 50 groups

9. Protection Sleeve Length 40mm, 60mm

10. Operating Language Chinese, English, French, Portuguese, Spanish

11. Operating Conditions -10~+50°C(operation temperature),0~95% RH(humidity), 0~5000m(altitude)

12. Power Supply AC adaptor: 100~240V input voltage, 50/60Hz; 12V, 5A output voltage(DC)

13. Inner lithium battery: 11.1V, 5.2AH

14. Storage of Splice Result 6,000 groups of latest splice results

15. Splicing Model Auto & Manual & Full Auto

16. Optical Fiber Fixture 3-in-1 cutting fixture; Multipurpose 1+N fixture (SC/LC/FC connector)
